The SSPY series is a Y-shaped stainless steel connector designed for smooth airflow splitting while minimizing pressure drop.
| Item Code | Tube Size(MM) |
|---|---|
| SSPY4 | 4 |
| SSPY6 | 6 |
| SSPY8 | 8 |
| SSPY10 | 10 |
| SSPY12 | 12 |
| SSPY16 | 16 |
| Item Code | Tube Size(Inch) |
| SSPY5/32 | 5/32 |
| SSPY1/4 | 1/4 |
| SSPY5/16 | 5/16 |
| SSPY3/8 | 3/8 |
| SSPY1/2 | 1/2 |
◎ FEATURES
-
Y-type branch layout for efficient flow division
-
316 stainless steel for maximum durability
-
Push-to-connect sealing on all ports
-
Reduced turbulence design
-
Available for various tube sizes
◎ APPLICATIONS
Ideal for branching air lines where balanced, low-resistance flow is required.
◎ SPECIFICATIONS
| Applicable Fluid Type | Air, Water,Vacuum | |
| Working Pressure Range | -14 ~150 PSI | -0.99~ 10 Bar |
| Working Temperature Range | 5 ℉~428℉ | -15℃~220℃ |
| Vacuum Rating | to 750mmHg | |
| Recommanded Tubings | PA11, PA12, PA6, PE, PU,PTFE,FEP | |
| Applications | Pneumatics, Food Industry, Chemical, Medical and Pharmaceutical Industry | |
About Logo: Standard No logo, OEM can be on request.
About Packing: you can choose Standard No Logo Packing, Idealer Logo Packing Or OEM packing.
