Project Description
Ideal Bell 316 Stainless Steel Push fitting female elbow is made of unique metal technology, using Imported stainless steel teeth, which can bite the tubing tighter with less demages. We 100% test leaking for all stainless steel push fittings in water before delivery. All of our stainless steel push fittings female elbows are REACH/ Rohs/Food compliance certified.
| Item Code | Tube Size(MM) | Thread |
|---|---|---|
| SSPLF4-M5 | 4 | M5x8 |
| SSPLF4-M6 | 4 | M6x1.0 |
| SSPLF4-01 | 4 | R 1/8 |
| SSPLF4-02 | 4 | R 1/4 |
| SSPLF6-M5 | 6 | M5x8 |
| SSPLF6-M6 | 6 | M6x1.0 |
| SSPLF6-01 | 6 | R 1/8 |
| SSPLF6-02 | 6 | R 1/4 |
| SSPLF6-03 | 6 | R 3/8 |
| SSPLF6-04 | 6 | R 1/2 |
| SSPLF8-01 | 8 | R 1/8 |
| SSPLF8-02 | 8 | R 1/4 |
| SSPLF8-03 | 8 | R 3/8 |
| SSPLF8-04 | 8 | R 1/2 |
| SSPLF10-01 | 10 | R 1/8 |
| SSPLF10-02 | 10 | R 1/4 |
| SSPLF10-03 | 10 | R 3/8 |
| SSPLF10-04 | 10 | R 1/2 |
| SSPLF12-01 | 12 | R 1/8 |
| SSPLF12-02 | 12 | R 1/4 |
| SSPLF12-03 | 12 | R 3/8 |
| SSPLF12-04 | 12 | R 1/2 |
| Item Code | Tube Size(MM) | Thread |
|---|---|---|
| SSPLF4-G01 | 4 | G 1/8 |
| SSPLF4-G02 | 4 | G 1/4 |
| SSPLF6-G01 | 6 | G 1/8 |
| SSPLF6-G02 | 6 | G 1/4 |
| SSPLF6-G03 | 6 | G 3/8 |
| SSPLF6-G04 | 6 | G 1/2 |
| SSPLF8-G01 | 8 | G 1/8 |
| SSPLF8-G02 | 8 | G 1/4 |
| SSPLF8-G03 | 8 | G 3/8 |
| SSPLF8-G04 | 8 | G 1/2 |
| SSPLF10-G01 | 10 | G 1/8 |
| SSPLF10-G02 | 10 | G 1/4 |
| SSPLF10-G03 | 10 | G 3/8 |
| SSPLF10-G04 | 10 | G 1/2 |
| SSPLF12-G01 | 12 | G 1/8 |
| SSPLF12-G02 | 12 | G 1/4 |
| SSPLF12-G03 | 12 | G 3/8 |
| SSPLF12-G04 | 12 | G 1/2 |
◎ FEATURES
This is our new line: Stainless Steel Push Fittings. Suitable for all those applications where brass nickel-plated and acetal fittings are banned, the new AISI 316L fitting is conceived to withstand corrosive environments (substances), to channel aggressive fluids and to be used in the food and chemical industries. Stainless Steel fittings line is standard equipped with FPM seals that will assure endurance at the highest temperatures.
◎ SPECIFICATIONS
| Applicable Fluid Type | Air, Water,Vacuum | |
| Working Pressure Range | -14 ~150 PSI | -0.99~ 10 Bar |
| Working Temperature Range | 5 ℉~428℉ | -15℃~220℃ |
| Vacuum Rating | to 750mmHg | |
| Recommanded Tubings | PA11, PA12, PA6, PE, PU,PTFE,FEP | |
| Applications | Pneumatics, Food Industry, Chemical, Medical and Pharmaceutical Industry | |
About Logo: Standard No logo, OEM can be on request.
About Packing: you can choose Standard No Logo Packing, Idealer Logo Packing Or OEM packing.
