Project Description

Brass 2/2 Way valve with direct acting or internal pilot and normally closed type 2/2 way, high sensibility, allows to change direction quickly. With compact, small size and light weight, Ideal Bell Brass 2/2 Way valve is easy to mount and dismantle.

Example  PU-220-01-AC110V-E
MeaningsModelAperture of
Flow Rate
Port SizeVoltageWiring Form
ExplainPU:two position two way solenoid valve
220:direct drive type
225: Pilot type
01:1/8"
02:1/4"
03:3/8"
04:1/2"
06:3/4"
08:1"
12:1 1/4"
14:1 1/2
20:2"
DC12V
DC24V
AC24V
AC36V
AC110V
AC220V
AC380V
blank:NBR
E:EPDM
V:VITON

PU

◎ FEATURES

1. Valve spool use best seals to guarantee the life time and consistency.
2. We apply high standard special grease which provides film in order to reduce friction.
3. High quality soft magnetic stainless steel to improve the magnetic performance and reduce coil capacity 30%.
